适用范围
1、1区、2区危险场所。
2、IIA、IIB、IIC类爆炸性气体环境。

Application
1、Can be used in Zone 1 and Zone 2 dangerous places.
2、Can be used in IIA、IIB、IIC group explosive atmosphere.

产品特点
1、可用于380/220V及以下电路中作为连接各种电气设备的
分线、接线用，也可作为自控或通讯的信号电源的连线。
2、外壳采用高强度难燃工程塑料压制而成，外形美观且具
有抗静电耐冲击及热稳定性好又耐腐蚀等优良性能。
3、盖与壳身之间设有密封圈，并用不锈钢螺钉紧固。
4、接线端子可采用压线式或菲尼克斯的增安型专用接线端
子。
5、端子数出线口方向及数量，公称直径可任意变化。
6、符合GB3836-2000，IEC60079标准要求。

Features
1、It is used to sub-connect or connect 380/220V and below electrical circuits, and also applicable to connect supply wire of self-
control engineering or communicaton’s signals.
2、The shell is made of high rigid, flame-proof engineering plastic with beautiful appearance, functions of electrostatic-resistant,
impulsion-withstanding, thermal stability and corrosion-proofing.etc.
3、Between cover and shell body is arranged seal washer fastened by stainless screw.
4、Terminal can be selected for line pressed type of pheonix’s special terminal of safety-increased type.
5、Terminal number, direction, nominal diameter may be changable.
6、Suitable for GB3836-2000, IEC60079 standard request.
